Technical Documentation

Sound On Paper

Put sound into paper — a privacy-first, QR-based audio sharing system built for artists who want to share sound as an intimate physical object

Next.js 15 · TypeScript · Postgres · Prisma · Web Crypto API · MinIO/R2 · Stripe

Pre-launch · All 10 milestones code-complete · 86 unit tests · 32/32 Playwright tests

Open the private beta →

The Idea

I watch my younger students reaching for analog. They're hunting down digicams, shooting film, buying cassettes. There's something they're after — something physical, personal, and real — that purely digital music sharing has removed. I've wanted to restore a physical dimension to sound for a long time. Not nostalgia exactly, but the feeling that music can be an object you hold, pass to someone, and give as a gift. Sound on Paper is built around that idea. A printed card with a song inside it. Snail mail for sound. The QR code generators already exist — this is the ecosystem, the experience, the thing that's been missing. A companion physical player is in development — the goal is a complete platform, not just a web app.

Control the paper = control the song.

What It Should Feel Like

It should feel like

a message passed by hand
a small art object
a secret song container
a minimalist music player
a physical-world sound object

It should not feel like

a promo landing page
a streaming smart link
a social profile
a CRM or marketing dashboard
a generic QR generator

Privacy Architecture

The privacy model is architectural. The server hosts encrypted sound objects and is deliberately designed so it cannot listen to them.

Client-side encryption

Audio, artwork, title, and message are encrypted in the browser before upload using AES-GCM via the Web Crypto API. The server stores only encrypted files, encrypted metadata, non-sensitive routing metadata, and aggregate event records. It never receives plaintext audio, titles, messages, or artwork.

URL fragment key

The QR code points to a URL shaped like:

https://soundonpaper.com/p/quiet-river-17#k=PUBLIC_SHARE_KEY

The slug quiet-river-17 is sent to the server. The fragment — everything after # — is never sent in normal HTTP requests. The browser uses it locally to decrypt the Piece. The server can serve the encrypted manifest without ever knowing the decryption key.

Dynamic QR

A printed QR code keeps working even when the creator changes the audio behind it. Each Piece has a stable public share key embedded in the QR at generation time. New audio versions are encrypted so the same printed paper decrypts the current assigned content. The creator's encrypted key set retains the Piece key so updates remain possible indefinitely. A printed QR can be updated to play different audio at any time without reprinting — the paper stays the same.

Key management

On account creation, a creator master key is generated in the browser. A recovery phrase — shown exactly once — can unlock it. Only encrypted key material is stored server-side. Trusted-device keys are stored as non-extractable CryptoKey objects in IndexedDB. If a creator loses their recovery phrase and has no trusted device, the company cannot recover their encrypted content. This is explained during setup in plain language without making the product feel like a security bunker.

Practical limits

The user-facing privacy promise is intimate and private — not magically impossible to copy. Client-side encryption prevents the company from reading stored content by default. It does not prevent a listener from recording audio from their device, sharing the QR link, or submitting the key during an abuse report. The product is honest about this distinction.

The Listener Experience

The listener page shows almost nothing by default: a large play button, an optional progress bar, optional title, optional short message, optional artwork. No creator identity, no promotional links, no social mechanics, no engagement bait.

A quiet response control — present like a small folded corner of paper — can reveal lightweight actions: a heart and a report. It is secondary to listening in every sense. Six themes — Plain Paper, Blank, Night Paper, Signal, Blue Hour, Red Room — provide restrained visual expression that feels like paper stocks, not decorative skins.

Playback pipeline

Listener browser shows staged loading messages: "Opening…", "Preparing sound…", "Almost ready…"
Fetches encrypted Piece manifest by slug
Reads share key from URL fragment — never sent to server
Decrypts manifest locally with Web Crypto
Fetches encrypted audio blob from object storage
Decrypts full audio blob in browser
Creates temporary object URL and plays via HTML audio element
In-flight fetches use AbortController for clean teardown

Build Status

The project is built in testable milestones — not because AI can't accelerate coding, but because the product has high-risk promises that must be validated incrementally. Each milestone leaves behind a working slice that is tested before more complexity is added.

0	Repo and App Foundation	Complete	Next.js 15, TypeScript strict, Tailwind v4, Prisma, Vitest, Playwright
1	Auth and Private Key Setup	Complete	Auth.js v5, PBKDF2 key derivation, IndexedDB non-extractable device keys, recovery phrase flow
2	Encrypted Audio Upload	Playwright accepted	AES-GCM browser encryption, presigned S3 upload, MP3/M4A validation, 3 min/10 MB limits
3	Piece Creation and Dynamic QR	Playwright accepted	Encrypted manifest, stable share keys, SVG/PNG QR export, word-word-NN slugs
4	Listener Playback	Playwright accepted	Browser-side decryption, one-tap playback, graceful errors for missing/invalid/wrong key
5	Themes and Listener Response	Playwright accepted	Six themes, heart toggle, report flow with key-sharing confirmation
6	Privacy-Friendly Analytics	Playwright accepted	Scan, play, completion events — no raw IP, no fingerprinting, no third-party scripts
7	Reporting, Copyright, Enforcement	Code complete	Abuse reports, DMCA/counter-notice intake, admin moderation UI, enforcement logging — acceptance pending admin account setup
8	Access Controls	Playwright accepted	Expiration, play limits, Pass-required Pieces, one-time and expiring Passes
9	Billing and Entitlements	Code complete	Stripe checkout/portal/webhook, plan-limit enforcement on Pieces and storage — acceptance pending Stripe test credentials
10	Print and Physical Artifact Tools	Playwright accepted	Sheet (A4), Card (85×54 mm), and Sticker (60×60 mm) print layouts, PDF export, optional URL beneath QR

86 unit tests pass. 32 of 32 Playwright acceptance tests pass against local MinIO. Remaining: M7 admin acceptance, M9 Stripe billing acceptance, mobile QR LAN testing.

In summary: Auth.js v5 with PBKDF2 key derivation and IndexedDB non-extractable trusted-device keys; encrypted audio upload to S3-compatible object storage; dynamic QR generation with stable fragment share keys; browser-side decryption with one-tap playback; six listener themes; privacy-friendly analytics with no raw IP retention; abuse reporting and DMCA intake with admin moderation UI; expiration, play limits, and Pass-gated listening; Stripe billing and plan enforcement; and printable PDF, card, and sticker layouts for physical QR artifacts.

Tech Stack

Framework	Next.js 15 App Router
Language	TypeScript (strict mode)
Styling	Tailwind CSS v4
Database	Postgres · Prisma ORM
Object storage	MinIO (local) · Cloudflare R2 / S3-compatible (production)
Browser encryption	Web Crypto API · AES-GCM · PBKDF2
Trusted device keys	IndexedDB · non-extractable AES-KW CryptoKey objects
Auth	Auth.js v5 credentials
Billing	Stripe checkout, portal, and webhook
QR generation	SVG and PNG export · error correction level H for sticker layout
Unit tests	Vitest · 86 passing
Acceptance tests	Playwright · 32/32 passing against local MinIO
Runtime target	Node 22 (.nvmrc + package.json engines)

Architecture

Route structure

app/
  (auth)/         signup, login, setup, unlock
  (creator)/      dashboard, audio, pieces, print, settings
  (listener)/p/   [slug] — public listener route
  (legal)/        copyright, privacy, terms, DMCA, counter-notice
  admin/          reports, copyright, enforcement
  api/            auth, key-vault, audio, pieces, public, admin, legal

Source structure

src/
  crypto/
    browser-crypto.ts      key generation, wrapping, unwrapping
    key-derivation.ts      PBKDF2 derivation from recovery phrase
    manifest-crypto.ts     Piece manifest encrypt/decrypt
    audio-crypto.ts        AES-GCM audio encrypt/decrypt
    device-key-store.ts    IndexedDB non-extractable CryptoKey storage
  lib/
    access-control.ts      expiry, play-limit, pass validation helpers
    billing.ts             Stripe customer, checkout, portal, webhook
    entitlements.ts        plan limits and enforcement
    events.ts              privacy-friendly event ingestion
    pass-code.ts           WORD-NN pass code generation
    qr.ts                  QR SVG generation for listener URLs and print
    slug.ts                word-word-NN slug generation
    storage.ts             S3-compatible object storage abstraction
    themes.ts              listener theme token definitions
    validation.ts          locked audio constraints (MP3/M4A, 10 MB, 3 min)

Prisma models

User · CreatorProfile · KeyVault
AudioAsset — plaintext: mimeType, sizeBytes; encrypted: name, durationMs
Piece — publicSlug, encryptedManifestBlob, encryptedPieceKeyForCreator, status, access controls
Pass — pieceId, code, maxUses, usesCount, expiresAt, status
PieceEvent — scan, play, play_complete, download; no raw IP stored
AbuseReport · CopyrightNotice · EnforcementAction
Subscription — plan, status, Stripe provider fields

Security Decisions

Audio encrypted with AES-GCM before leaving the browser — server never sees plaintext
Recovery phrase never sent to server — PBKDF2 derivation is browser-only
Trusted-device keys stored as non-extractable CryptoKey objects in IndexedDB — cannot be exported or read by JavaScript after creation
Share key kept in URL fragment — not sent in HTTP requests, not logged server-side
Two-phase setup flow — local trusted-device key is verified before the server vault is written, preventing an unrecoverable first-run state
Pass consumption uses conditional atomic increment — concurrent requests cannot exceed maxUses
importShareKey validates decoded key is exactly 32 bytes before passing to Web Crypto — deterministic error for malformed keys
Suspended users cannot sign in
Non-active Piece IDs injected into print preview query string are rejected server-side

Moderation and Safety

The privacy model creates a real tension with safety. The product does not pretend otherwise. The principle: no surveillance, clear safety boundaries, human review only when someone with access reports abuse.

When a listener files a report, the flow explains that submitting it shares the full Piece URL — including the fragment key — with moderation. This is an explicit, informed action. Moderators can decrypt and review reported Pieces, disable Piece routes, record copyright notices, and log enforcement actions against accounts. DMCA notice and counter-notice intake is built into the legal pages. Repeat-infringer tracking is modeled in the data schema.

Product Guardrails

Do not turn this into a link-in-bio product
Do not add external music service links in the MVP
Do not upload plaintext audio to the server
Do not store plaintext titles, messages, artwork, or audio
Do not use magic-link-only login
Do not add ads or social mechanics to listener pages
Do not add per-upload copyright checkboxes
Do not promise guaranteed autoplay
Do not add proactive copyright scanning of encrypted audio
